Victron

Victron Quattro 5000 va, 48 volt inverter/Charger

Victron Quattro 5000 va, 48 volt inverter/Charger

$3,448.00 AUD
$4,311.00 AUD $3,448.00 AUD
Sale Sold out
Shipping calculated at checkout.

Victron Inverter/Charger, Quattro 48/5000/70-100/100

The Victron Quattro 48/5000/70-100/100 Inverter/Charger is a powerful true sine wave inverter, is a sophisticated battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact enclosure.

The unit is extremely reliable and sturdy owing to its strong powder coated steel casing, PCB Construction and full electronic fault protection.

UP TO 5 YEAR WARRANTY - SUPER HIGH RELIABILITY





Output power continuous:

5000VA

Dimensions (mm):

444h x 328w x 240d

Output watts continuous :

4000W

Mass:

30Kg

Output power surge:

10000W

Battery high protection:

Yes

Input voltage:

38-66V

Battery low protection:

Yes

Standby current:

25W

Overload protection:

Yes

Output frequency:

50Hz +/-0.1%

Over temp protection:

Yes

Output voltage:

230 Vac Sine

Thermal fan:

Yes

Output regulation:

Sine, <5%THD

Output Power LCD:

No

Efficiency:

95%

Fault LED:

Yes

Selectable demand start:

Yes

Audible alarm:

Yes

Output isolation:

Yes

Remote control:

Optional

Battery Charger 5 stage:

Yes

Solar Charger:

No

Battery Charger Current:

70 Amps

Generator Support:

Yes

Aux Battery charger:

N/A

Solar Charger Current:

N/A

Automatic load transfer:

Yes

Automatic Generator Start:

Yes

 Number of AC inputs:

 2

 Number of AC outputs:

 2






FREIGHT: $30 anywhere in Australia

 DOWNLOAD DATA SHEET PDF

DOWNLOAD MANUAL PDF
