EasySolar-II 48/5000/70-50 MPPT250/100 GX
EasySolar-II 48/5000/70-50 MPPT250/100 GX
All in-one solar power solution.
The EasySolar combines a MPPT solar charge controller, an inverter/charger and AC distribution in one enclosure.
The product is easy to install. with minimum of wiring.
The solar charge controller, Blue Solar MPPT 250/100.
250 volt, 70 amp MPPT solar charger.
The Inverter/Charger: MultiPlus 48/5000/70-50.
The MPPT charge controller and the MultiPlus Compact inverter/charger share the DC battery cables .The batteries can be charged with solar(SmartSolarMPPT) and/or with AC power (inverter/charger) from the utility grid or a genset.
AC distribution
The AC distribution consists of a RCD (30mA/16 A) and four AC outputs protected by two 10A and two 16A circuit breakers.
One additional 16A output is controlled by the AC input: it will switch on only when AC is available.
PowerAssist
Unique PowerAssist technology protects the utility or generator supply from being overloaded by adding extra inverter power when needed.
Unique solar application software.
Several software programs (Assistants) are available to configure the system for various grid interactive or stand-alone applications.
Download Data Sheet:
5 YEAR WARRANTY - SUPER HIGH RELIABILITY
Output power continuous: |
5000VA/4000W |
Dimensions (mm): |
604h x 323w x 258d |
Output power surge: |
9000W |
Mass: |
39Kg |
Heavy duty output AC0: |
16A |
Battery high protection: |
Yes |
Input voltage: |
38-66V |
Battery low protection: |
Yes |
Standby current: |
2 - 18W |
Overload protection: |
Yes |
Output frequency: |
50Hz +/-0.1% |
Over temp protection: |
Yes |
Output voltage: |
230 Vac Sine |
Thermal fan: |
Yes |
Output regulation: |
Sine, <5%THD |
Output Power Indicator: |
Yes |
Efficiency: |
96% |
Fault LED: |
Yes |
Programable demand start: |
Yes |
Audible alarm: |
No |
Output isolation: |
Yes |
Remote control: |
Yes |
Battery Charger multi stage: |
Yes |
Solar Charger: |
Yes |
Battery Charger Current: |
70 Amps |
Generator Support: |
Yes |
Aux Battery charger: |
No |
Solar Charger Current: |
70 Amps MPPT |
Automatic load transfer: |
Yes |
Automatic Generator Start: |
Yes |
|
|
|
|
