Victron Energy

EasySolar-II 48/3000/34-32 MPPT 250/70 GX

EasySolar-II 48/3000/34-32 MPPT 250/70 GX

$3,499.00 AUD
$3,923.00 AUD $3,499.00 AUD
Sale Sold out



All in-one solar power solution.
The EasySolar combines a MPPT solar charge controller, an inverter/charger and AC distribution in one enclosure.
The product is easy to install. with minimum of wiring.
The solar charge controller, Blue Solar MPPT 250/70.
250 volt, 70 amp MPPT solar charger.
The Inverter/Charger: MultiPlus 48/3000/35-50.
The MPPT charge controller and the MultiPlus Compact inverter/charger share the DC battery cables .The batteries can be charged with solar(SmartSolarMPPT) and/or with AC power (inverter/charger) from the utility grid or a genset.
AC distribution
The AC distribution consists of a RCD (30mA/16 A) and four AC outputs protected by two 10A and two 16A circuit breakers.
One additional 16A output is controlled by the AC input: it will switch on only when AC is available.
PowerAssist
Unique PowerAssist technology protects the utility or generator supply from being overloaded by adding extra inverter power when needed.
Unique solar application software.
Several software programs (Assistants) are available to configure the system for various grid interactive or stand-alone applications.


Download Data Sheet:

5 YEAR WARRANTY - SUPER HIGH RELIABILITY



Output power continuous:

3000VA/2400W

Dimensions (mm):

810h x 258w x 218d

Output power surge:

6000W

Mass:

28Kg

Heavy duty output AC0:

16A

Battery high protection:

Yes

Input voltage:

38-66V

Battery low protection:

Yes

Standby current:

2 - 11W

Overload protection:

Yes

Output frequency:

50Hz +/-0.1%

Over temp protection:

Yes

Output voltage:

230 Vac Sine

Thermal fan:

Yes

Output regulation:

Sine, <5%THD

Output Power Indicator:

Yes

Efficiency:

95%

Fault LED:

Yes

Programable demand start:

Yes

Audible alarm:

No

Output isolation:

Yes

Remote control:

Yes

Battery Charger multi stage:

Yes

Solar Charger:

Yes

Battery Charger Current:

70 Amps

Generator Support:

Yes

Aux Battery charger:

No

Solar Charger Current:

70 Amps MPPT

Automatic load transfer:

Yes

Automatic Generator Start:

Yes









 FREIGHT: $50 anywhere in Australia
