Victron Energy

EasySolar 24/1600/40

EasySolar 24/1600/40

$2,485.00 AUD
$2,762.10 AUD $2,485.00 AUD
Sale Sold out
Shipping calculated at checkout.



All in-one solar power solution.
The EasySolar combines a MPPT solar charge controller, an inverter/charger and AC distribution in one enclosure.
The product is easy to install. with minimum of wiring.
The solar charge controller, Blue Solar MPPT 100/50.
Up to three strings of PV panels can be connected to 3three sets of MC$(PV-ST01) PV connectors
The Inverter/Charger: MultiPlus Compact 24/1600/40.
The MPPT charge controller and the MultiPlus Compact inverter/charger share the DC battery cables (included).The batteries can be chargedwith solar(SmartSolarMPPT) and/or with AC power (inverter/charger) from the utility grid or a genset.
AC distribution
The AC distribution consists of a RCD (30mA/16 A) and four AC outputs protected by two 10A and two 16A circuit breakers.
One 16A output is controlled by the AC input: it will switch on only when AC is available.
PowerAssist
Unique PowerAssist technology protects the utility or generator supply from being overloaded by adding extra inverter power when needed.
Unique solar application software.
Several software programs (Assistants) are available to configure the system for various grid interactive or stand-alone applications.

5 YEAR WARRANTY - SUPER HIGH RELIABILITY

Download Data Seet:



Output power continuous:

1600VA/1300W

Dimensions (mm):

745h x 214w x 110d

Output power surge:

3000W

Mass:

15Kg

Heavy duty output AC0:

16A

Battery high protection:

Yes

Input voltage:

19-33V

Battery low protection:

Yes

Standby current:

3 - 10W

Overload protection:

Yes

Output frequency:

50Hz +/-0.1%

Over temp protection:

Yes

Output voltage:

230 Vac Sine

Thermal fan:

Yes

Output regulation:

Sine, <5%THD

Output Power Indicator:

Yes

Efficiency:

94%

Fault LED:

Yes

Programable demand start:

Yes

Audible alarm:

No

Output isolation:

Yes

Remote control:

Optional

Battery Charger multi stage:

Yes

Solar Charger:

Yes

Battery Charger Current:

40 Amps

Generator Support:

Yes

Aux Battery charger:

4 Amps

Solar Charger Current:

50 Amps MPPT

Automatic load transfer:

Yes

Automatic Generator Start:

Yes









 FREIGHT: $40 anywhere in Australia
