Battery Charger, 12 Volt, 100 Amp 3 battery Bank Centaur Charger 12/100(3) 120-240V
Battery Charger, 12 Volt, 100 Amp 3 battery Bank Centaur Charger 12/100(3) 120-240V
Quality without compromise
Aluminum epoxy powder coated cases with drip shield and stainless steel fixings withstand the rigors of an
adverse environment: heat, humidity and salt air.
Circuit boards are protected with an acrylic coating for maximum corrosion resistance.
Temperature sensors ensure that power components will always operate within specified limits, if needed by
automatic reduction of output current under extreme environmental conditions.
Universal 90-265V AC input voltage range and also suitable for DC supply (AC-DC and DC-DC operation)
All models will operate without any adjustment needed over a 90 to 265 Volt input voltage range, whether
50 Hz or 60 Hz.
The chargers also accept a 90-400 V DC supply.
Three outputs that each can supply the full output current
Three isolated outputs to simultaneously charge 3 battery banks
Each output is capable to supply the full rated current.
Three-stage charging, with temperature compensation
The Centaur charges at bulk rate until the output has reduced to 70% of the rated Amps, at which a 4 hour timer
begins. After the timed period the charger switches to float rate.
An internal temperature sensor is used to compensate the charge voltage with – 2 mV/ºC (– 1 mV/ºF) per cell.
A DIP switch is available to select the optimum charge/float voltages for Flooded Lead-acid, Gel or AGM
batteries.
5 YEAR WARRANTY
FREIGHT FREE!!
Output Current continuous: |
100 Amps |
Dimensions (mm): |
524h x 252w x 123d |
Output Current Surge: |
100 Amps |
Mass: |
12Kg |
Output Voltage: |
12 Volts: |
Input Fuse protection: |
Yes |
Input voltage: |
90-265 Volts |
Reverse Polarity protection: |
Yes |
Input current: |
10 Amps Max |
Fully Charged indicator: |
No |
Input frequency: |
45- 65 Hz |
Over temp protection: |
Yes |
Output Boost voltage: |
14.3 VDC |
Thermal fan: |
Yes |
Output Float Voltage: |
13.5 VDC |
Battery Type Selection Switch: |
No |
Amp Meter: |
Yes |
Input Power lead: |
No
|
FREIGHT: Free
